Mechanical Foam
Safe-T PLUS Stored pressure Foam Extinguishers are ideal for fires involving volatile liquids, petrol, kerosene and freely burning materials such as paper ,cloth, wood and furniture.
Features
- CE Marked Extinguishers (9 Ltrs only)
- CE Marked Squeeze Valves with Safety Pressure Release Valve
- EPDM Hose
- High quality epoxy polyester powder coating
- Controlled discharge
- Brass nickel plated head valve with simple squeeze operation
- Unique gauge testing system (UGTS)
- Easy & more economical to maintain & service
- Spl. Bracket Alarm
- International Color Coding Operation Sticker
| PERFORMANCE DATA | ||||
| MODEL | UFM 6 | UFM 9 | ||
| Capacity | 6L | 9L | ||
| Fire Rating | 1A : 13B | 4A : 34B | ||
| Average discharge time | 25 sec | 40 sec | ||
| Height (Approx.) | 530 mm | 585 mm | ||
| Diameter (Approx) | 150 mm ± 10 mm | 180 mm ± 10 mm | ||
| Filled weight (Approx.) | 10 Kg | 13 Kg. | ||
| Empty weight (Approx) | 4 Kg | 4.7 Kg | ||
| Operating temperature | +5°C to +55°C | +5°C to + 55°C | ||
| Working Pressure at 20° C | 15 bar | 14 bar | ||
| Maximum Service Pressure | 18 bar | 18 bar | ||
| Test Pressure | 35 bar | 35 bar | ||
| Approval | Under Approval | BIS & CE | ||
