Powder Series (ABC)

convex
Safe-T Dry Powder extinguishers are characterized by their high performance, simple method of operation and rapid fire knock down capability. They are suitable for tackling fires involving freely burning materials, petrol & oils, gas & electrical equipment. They are ideal for vehicle & marine risks. Safe-T powder extinguishers contain high performance powder to achieve high Fire Rating.

Suitable for Classes:

Ideal Use:

Homes, office, Buildings warehouses, Farms and Wood working area etc.

FIRE RATING AS PER IS 15683 2006
MODEL A B
UFD 1 - 8B
UFD 2 - 8B
UFD 4 2A 21B
UFD 6 3A 21B
UFD 9 3A 21B

Features

  • Mono – ammonium phosphate based dry chemical agent. Capable of fighting class A, B, C & E fires as per IS 14609
  • BIS Approved ( IS 15683 )
  • CE Certified (On Request)
  • High quality pure polyester powder coating
  • Controlled discharge
  • Brass nickel plated head valve with simple squeeze operation
  • Unique gauge testing system (UGTS)
  • Easy & more economical to maintain & service
  • Rechargeable and easy to service
  • Choice of capacity from 1 to 9 Kg
  • High quality EPDM Rubber braided hose is far more flexible than the normal rubber used in hose pipe and also far less prone to cracks.
PERFORMANCE DATA
MODEL UFD 1 UFD 2 UFD 4 UFD 6 UFD 9
Capacity 1 Kg 2 Kg 4 Kg 6 Kg 9 Kg
Fire Rating 8B 8B 2A:21B 3A:21B 3A:21B
Average discharge time 9.0 sec 14.0 sec 18.0 sec 21.0 sec 23.0 sec
Height without base 325 mm 390 mm 500 mm 530 mm 600 mm
Diameter (Approx) 86 ± 10 mm 108 mm 140 mm 150 mm 180 mm
Filled weight (Approx) 2 Kg. 3.4 Kg. 6.7 Kg. 9 Kg. 13.18 Kg.
Empty weight (Approx) 1 Kg. 1.4 Kg. 2.7 Kg. 3 Kg. 4.18 Kg.
Operating temperature -30°C to 55°C
Working Pressure at 20° C 15 bar 15 bar 15 bar 15 bar 15 bar
Maximum Service Pressure 18 bar 18 bar 18 bar 18 bar 18 bar
Test Pressure 35 bar 35 bar 35 bar 35 bar 35 bar
Approval BIS & CE BIS & CE BIS & CE BIS & CE BIS & CE
